Model SR-FSJ-300/1500

Application

It is suitable for automatically packaging of viscous products with free-flowing such as tomato sauce, honey, lotion  etc. The integrated processes of bag making, measuring, filling, sealing, cutting, counting and hot pressing codes can be done automatically.

Feature

1. All SS04 stainless steel cover meets to international GMP standard.

2. Automatic adjustment of filling range and packing speed.

3. Adopt piston pump as measuring and filling device which can make sure accuracy.

4. The quick release coupling can make sure the easy washing of the machine.

5. Adopting special rotary valve can pack the products with small granule material inside.

6. The special design for longitudinal sealing with close sealing line can make sure sealing area strong with no jam and prolong the valid time of product.

7. Adopt intelligent photocell for automatic tracking; make sure the pattern complete and beautiful.

8. Bag type can be 3 sides sealing, 4 sides sealing and Pillow shape bag or special bottleneck sealing.

9. Along with assembling automatic no packing alarm system, when the packing material is used out, machine can stop automatically and help user to economize cost

10.  Ink roller printer can be equipped to print the production date, valid  date and batch number on packing material or can choose free hot pressing code.

Main technical parameters


FSJ-300

Bag size

L:80-220mm W:40-150mm

Capacity

30-60(bags/min)

Filling range

50-300ml

Dimension(LxWxH)

1100mmx900mmx1900mm

Weight

300kg

FSJ-1500

Bag size

L:100-300mm W:40-175mm

Capacity

28-60(bags/min)

Filling range

50-1400ml

Dimension(LxWxH)

1200mmx800mmx2000mm

Weight

350kg

Power

220V,50HZ,1.3KW

*Depending on product property and filling volume
