Model SR-FS-F500 / F620 / F800

Application

This machine adopt screw conveying material, and the storage can be vibrated . It is suitable for conveying various powder and little pellets.

Feature

Main Packing machine

1. Imported PLC computer control system with human-machine interface;

2. Minimize the loss with complete automatic warn protection function;
3. Supported with metric device, the machine will automatically complete all

packaging processes from measuring, feeding, filling, bag making.

Model

 Type 500

Type 620

Type 800

Film width

180-550mm

220-600mm

340-800mm

Bag width

80-240mm

100-300mm

160-385mm

Bag lengh

50-300mm

50-380mm

100-480mm

Capacity

15-60bags/min

15-60bags/min

10-30bags/min

Air consumption:

0.36m3/Min,0.6MPa

0.4m3/Min,0.6MPa

0.7m3/Min,0.6MPa

Power:

220V, 50HZ, 3KW

220V, 50HZ, 4.5KW

220V, 50HZ, 4.5KW

Weight:

550Kg

680Kg

980Kg

Dimension(L*W*H)

1550*1160*1480mm

1600*1260*1680mm

1600*1500*2050mm



Screw metering machine

The machine applies whirl threaded rod feeding, servo coding and micro-computer control technology.

Items

Content

Matering system

Screw rotary filling

Packaging weight

10-2000g (alter screw accessory)

Packaging precision

=100g accuracy=0.5-1g

100-1000g accuracy=0.5%-1g

>1000g accuracy:0.25%-0.5%

Packaging speed

10-50 bags/min

voltage

Three phase 380v ( AC 220v) 50-60HZ

Machine power

1.5kw

Machine weight

80kg

Volume

50L




Screw feeding conveyor

This machine adopt screw conveying material, and the storage can be vibrated. it is suitable for conveying various powder and little pellets.

Items

Content

Lifting height

Screw rotary filling

Lifting volume

10-2000g (alter screw accessory)

Specification

10-50 bags/min

Material

Three phase 380v (AC 220v) 50-60HZ




Finished products conveyer

The machine can send the packed finished bag to after-package detecting device or packing platform.

Items

Content

Feeding speed

30m/minute

Dimension(LxWxH)

2110mmx340mmx500mm

Voltage

220V/45W


Other Picture

Machine video
