Model SR-FSK-300/1500

SR-FSK-1500 300.gif

Application

The machine is suitable for packing all kinds of free flowing, non sticky products, such as washing powder, coffee, tea, sugar, peanut, oatmeal, etc.

The integrated process of bag making, measuring, filling, sealing, cutting and counting can be done automatically.

Packing materials: heat-sealable lamination, such as PET/VMPET/PE, PET/PE, NYLON/PE, etc.





Feature

1. Filling capacity is up to 1500ml, energy saving up to 50%.

2. Adopts mill type filling system, loss prevention, speed improving, avoid sticking to the sealing area.

3. Adopts smart photocell for automatic tracking, which guarantees the pattern on the packing material complete and beautiful.

4. Low noise, stable operation, long life cycle ( more than 10 years ).

5. Unique easy cleaning system makes changing filling material and maintenance comvenient and time saving.

Main technical parameters

SR-FSK-300

                    Bag size

  L:40-190 mm  W:30-110 mm

                    Capacity

              30-60 bags/min

                 Filling range

                   5-160 ml

                      Power

         220 V,50 HZ,1.5 KW

                     Weight

                     300 kg

           Dimension(L*W*H)

            820x695x1740 mm

SR-FSK-1500

                     Bag size

  L:100-300 mm  W:40-190 mm

                     Capacity

              15-50 bags/min

                  Filling range

                 50-1500 ml

                      Power

         220 V,50 HZ,1.5 KW

                     Weight

                   350 kg

           Dimension (L*W*H)

           1200x800x2000 mm

        Ideal Thickness of Flim

                 65μm-75μm

   Depending on product property and filling volume
