Tea Bag Packing Line



Application

This machine is suitable for health-care tea, herbal tea, fruit tea, and other granular materials.

It adopts food grade non-woven nylon material which has good water permeability and perceptivity, achieves a beautiful and harmonious vision.

The latest tea packing machine can present different tea-drink experiences and visual effects.

Inner tea bag can be put into outer envelope by this packing line, singly and a couple.

Feature

1. Adopt servo motors + PLC and color touch screen control system, easy operation.

2. The most advanced and safest tea packing method: ultrasonic sealing for inner nylon teabag.

3. Easily change between triangle bag and square bag.

4. Automatically attached Thread & Tag.

5. Various options for filling range and bag size.

6. Optional highly efficient volumetric feeder or combination scale type feeder which is controlled by color touch screen.

7. Ultrasonic sealer & cutter operated via servo motors to ensure stable sealing of filter material/thread/tag.

8. Multi-bag packing into one envelope and single bag packing into one envelope are options.

9. Optional cellophane overwrapping machine for tea box wrapping.

Main technical parameters


Model SR-FSCH-10D

Capacity

50bags/min

Filling Range

1.5-10g

Bag Size

Pyramid Bag Width

Flat Bag



50-80mm

L:40-80mm W: 60-90mm

Power

220v 50Hz 1.8kW

Compressed air

pressure

0.6MPA

Air consumption

0.2L/min

Depending on your product property and filling volume.



Other Picture




Machine video
