Model SR-FSM-250II

Application

This is an integrated producing packaging line, which is widely adopted in Tobacco Honey

 processing scope, achieved complete procedure of bag forming, filling, sealing,

cartoning as well as cellophane overwrapping, with high efficiency and precise packing effect.

This machine could increase your product market share by offering a better quality product than

your competitors.



Feature

1. According to different specialty of molasses product,this machine adopts vertical and horizontal feeding and measuring system.



2. Equipped with easy washing system, to make changing different flavors of molasses priduct convenient and easy.



3. We are able to provide whole line of molasses packing: pillow bag → cartoning → carton cellophane → boxing → box cellophane.



4. With mixer inside the hopper, to make sure feeding evenly and smoothly.



5. Packaging speed can be increased while monitoring the sealing quality.



6. Screw feeding conveyor is an option.


Main technical parameters

FSM-250II

Pouch size

(L)100-300mm (W)40-175mm

Capacity*

28-60bags/min

Filling range

200-1400ml

Dimension(LxWxH)

1200mm x 800mm x 2000mm

Weight

350kg

Power

220V,50HZ,1.3KW



*Depending on product property and filling range

Other Picture

Machine video
